Specifications – Panasonic FZ-A1 series User Manual
Page 26
26
Specifications
Main Specifications
Model No.
FZ-A1BDAAZAM / FZ-A1BDAAZCE
CPU/Secondary cache memory
Marvell PXA2128, Dual Core CPU, 1.20 GHz
Main Memory
1 GB*
1
Storage
16 GB*
2
(Flash memory)
Display Method
10.1 type (TFT) (1024 × 768 dots)
Touchscreen
Multi-touch screen and digitizer
Wi-Fi
IEEE 802.11 a/b/g/n
Bluetooth*
3
v 2.1 +EDR
Wireless WAN*
4
3G/LTE module
GPS
built-in
Card Slots
microSD Memory Card Slot*
5
microSDHC compatible × 1
SIM Card Slot
× 1*
4
Interface
USB 2.0 Micro-B connector × 1*
6
/ HDMI Micro connector*
7
/ Microphone & Headphone Jack / Expansion Bus
Connector (Use as an extension in the future)
Camera
Front: 2.0 Mega pixel, fixed focus
Rear: 5.0 Mega pixel with LED flash, auto focus
Sensor
Digital Compass, Accelerometer, Ambient light sensor
Power Supply
AC adaptor or internal battery
AC Adaptor*
8
Input: 100 V - 240 V AC, 50 Hz/60 Hz
Output: 12 V DC, 2 A
Battery
Li-ion 7.4 V, Typical 4770 mAh / Minimum 4590 mAh
Operating Time*
9
Approx. 10 hours
Charging Time*
10
90 % charging time: Approx. 2.5 hours (in sleep mode)
Physical Dimensions (W × D × H)
266.3 mm × 17.5 mm × 212.0 mm {10.5″ Ч 0.7″ Ч 8.4″}
Weight
Approx. 0.993 kg {2.19 lb.}
Environment Operating
Temperature
-10 °C to 50 °C {14 °F to 122 °F} (IEC60068-2-1, 2)*
11
Humidity
30 to 80 % RH (No condensation)
Storage
Temperature
- 20 °C to 60 °C {4 °F to 140 °F}
Humidity
30 % to 90 % RH (No condensation)
OS*
12
Android 4.0 (Ice Cream Sandwich)
Pre-installed Software
Adobe Reader, AuthenTec QuickSec, Dashboard, Device
Management, McAfee Mobile Security (Trial version), Pen
Calibration, Google applications*
13
Approx. 0.9 W of power is consumed when the battery is fully charged (or not being charged) and this
computer is off.
Even when the AC adaptor is not connected to this computer, max. 0.3 W of power is consumed simply
by having the AC adaptor plugged into an AC outlet.
*
1
1 GB = 1,073,741,824 bytes
*
2
1 GB = 1,000,000,000 bytes. Your operating system or some application will report as fewer GB. Approx.
3 GB*
1
is used as system area.
*
3
Does not guarantee operation of all bluetooth peripherals.
*
4
On
*
5
Th
Pa
eq
*
6
Do
*
7
Do
*
8
Th * 9 Me de * 10 Va * 11 Do W * 12 An * 13 De This o (5) o - of th Appendix
wi
en
Us
typ
W
be
ma
(1) t
(2) t
(3) t
(4) t
For
v2.1
http
http
In ad
the
The
with
At le
at th
sour
und
Con
oss-
For
