PLANET NOVASwitch series 10
1.4 Specifications
Standard IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x
Network
Media:
10Base-T,UTP/STP category 3 or 5 cable
100Base-TX,UTP/STP category 5 cable
1000Base-T,UTP/STP category 5e cable, 4 pairs
1000Base-SX,Multi-mode 62.5/125 μm, 50/125μm
fiber optic cable
Connector
STP RJ-45 port for 10/100/1000MbpsTX
SC connector for 1000Mbps SX
LED
indicators
Power, Smart
Individual port (copper) —1000,100,10
FDX/COL, TX, RX
Individual port (fiber) —Link, Activity
Dimension 440mm(L) x 245mm(W) x 45mm(H)
Temperature Operating —0℃ to 40℃ Storage—20℃ to 70℃
Humidity:
Operating — 10% to 90%RH
Storage — 5% to 90%RH
Input Power
Requirement
100-240VAC,50-60Hz,Auto-sensing
Registrations FCC Class A,CE,CUL,TUV,LVD
*After module installed
