● IEEE 802.3x flow control for full duplex operation and Backpressure for half
duplex operation
● Integrated address look-up engine, support 8K absolute MAC addresses
● 9K Jumbo packet support
● Automatic address learning and address aging
● Supports Auto MDI/MDI-X function
● Support CSMA/CD protocol
● 100~240VAC, 0.6A, 50~60Hz universal Power input
● FCC, CE class A compliant
1.4 Product Specifications
Product GSW-1601 GSW-2401
Hardware Specification
10/100/1000Base-T MDI/MDIX
Ports
16 24
Throughput (packet per second) 23.8Mpps 35.7Mpps
Switch fabric 32Gbps 48Gbps
Weight 2.50kg 2.71kg
Power Consumption / Dissipation 21 watts / 71 BTU 34 watts / 116 BTU
Power Requirement 100~240 VAC, 0.6A, 50-60 Hz
Dimensions (W x D x H) 440 x 180 x 45mm, 1U height
Switch Processing Scheme Store-and-Forward
Address Table 8K entries
Jumbo packet size 9K
Flow Control
Back pressure for half duplex, IEEE 802.3x Pause
Frame for full duplex
Temperature
Operating: 0~50 degree C
Storage -40~70 degree
Humidity Operating: 5% to 90%, Storage: 5% to 90% (Non-condensing)
Standards Conformance
Regulation Compliance
FCC Part 15 Class A, CE
Standards Compliance
IEEE 802.3 (Ethernet)
IEEE 802.3u (Fast Ethernet)
IEEE 802.3ab(Gigabit Ethernet)
IEEE 802.3x (Full-duplex flow control)
