Patton electronic 2040 - Manual (Page 2)

©
Bi-Directional HSSI (High Speed Serial
Interface) Conversion
©
Three Models to Choose From:
Patton 2040 - V.35 to HSSI
Patton 2041 - X.21 to HSSI (pictured)
Patton 2042 - RS-530 to HSSI
©
Sup
up
© Tran
Con
© Integ
©
Two
DT
©
Exte
Data Format: Synchronous
Standards: Converts CCITT V.35, CCITT X.21 or
EIA-530 to HSSI (ANSI/TIA/EIA-613, December,
1993 & ANSI/TIA/EIA-613, November, 1993)
Data Rate: 0 - 10 Mbps
Clocking: All clocking modes supported except con-
version from smooth to gapped clock
Loopbacks: Local line and remote line supported;
Local DTE not available
Interfaces: V.35, X.21 or RS-530 DTE to HSSI
DCE
(see
Connec
Male
DB-2
Cable:
Temper
Altitude
Humidi
Power
100-
Dimens
(12.4
Patto
5.08
7622 Rickenbacker Dr., Gaithersburg, MD 20879
Phone: (301) 975-1000 • Fax: (301) 869-9293 • E-mail: sales@p
O
RDERING
I
NFO
O
RDERING
I
NFO
2040MT-MC/UI (M/34 male, V.35 DTE configuration) to
Universal Input Power Supply (100 -
2040MC-MT/UI (M/34 male, V.35 DCE configuration) to
Universal Input Power Supply (100 -
2041FT-MC/UI (DB-15 female, X.21 DTE configuration
Universal Input Power Supply (100 -
2041FC-MT/UI (DB-15 female, X.21 DCE configuration
Universal Input Power Supply (100 -
2042MT-MC/UI (DB-25 male, RS-530 DTE configuratio
Universal Input Power Supply (100 -
2042MC-MT/UI (DB-25 male, RS-530 DCE configuratio
Universal Input Power Supply (100 -
S
PECIFICATIONS
S
PECIFICATIONS
Patton
V.35/X.
F
EATURES
F
EATURES
©
Bi-Directional HSSI (High Speed Serial
Interface) Conversion
©
Three Models to Choose From:
Patton 2040 - V.35 to HSSI
Patton 2041 - X.21 to HSSI (pictured)
Patton 2042 - RS-530 to HSSI
©
Supports Synchronous Data Rates
up to 10 Mbps
© Transparent to Protocol–Passes Data,
Control Lines and Two Loopback Modes
© Integral 6 ft (1.8 m) Cable
©
Two Versions: DCE-to-DTE and
DTE-to-DCE
©
External AC Power Supply
Data Format: Synchronous
Standards: Converts CCITT V.35, CCITT X.21 or
EIA-530 to HSSI (ANSI/TIA/EIA-613, December,
1993 & ANSI/TIA/EIA-613, November, 1993)
Data Rate: 0 - 10 Mbps
Clocking: All clocking modes supported except con-
version from smooth to gapped clock
Loopbacks: Local line and remote line supported;
Local DTE not available
Interfaces: V.35, X.21 or RS-530 DTE to HSSI
DCE; V.35 X.21 or RS-530 DCE to HSSI DTE
(see ordering information)
Connectors: Male HD/Slimline 50-pin (HSSI);
Male M/34 (V.35), Female DB-15 (X.21) or Male
DB-25 (RS-530)
Cable: 6 ft (1.8 m)
Temperature Range: 32-122°F (0-50°C)
Altitude: 0-15,000 feet (4.5Km)
Humidity: Up to 95% non-condensing
Power Supply: External AC transformer,
100-240VAC (Universal Input), IEC-320 connector
Dimensions: Patton 2040 - 4.90” x 2.00” x 0.73”
(12.45 cm x 5.08 cm x 1.85 cm); Patton 2041 and
Patton 2042 - 3.40” x 2.00” x 0.73” (8.63 cm x
5.08 cm x 1.85 cm)
7622 Rickenbacker Dr., Gaithersburg, MD 20879
Phone: (301) 975-1000 • Fax: (301) 869-9293 • E-mail: [email protected] • WWW: http://www.patton.com
O
RDERING
I
NFO
O
RDERING
I
NFO
2040MT-MC/UI (M/34 male, V.35 DTE configuration) to (HD-50 male, HSSI DCE configuration),
Universal Input Power Supply (100 - 240VAC)
2040MC-MT/UI (M/34 male, V.35 DCE configuration) to (HD-50 male, HSSI DTE configuration),
Universal Input Power Supply (100 - 240VAC)
2041FT-MC/UI (DB-15 female, X.21 DTE configuration) to (HD-50 male, HSSI DCE configuration),
Universal Input Power Supply (100 - 240VAC)
2041FC-MT/UI (DB-15 female, X.21 DCE configuration) to (HD-50 male, HSSI DTE configuration),
Universal Input Power Supply (100 - 240VAC)
2042MT-MC/UI (DB-25 male, RS-530 DTE configuration) to (HD-50 male, HSSI DCE configuration),
Universal Input Power Supply (100 - 240VAC)
2042MC-MT/UI (DB-25 male, RS-530 DCE configuration) to (HD-50 male, HSSI DTE configuration),
Universal Input Power Supply (100 - 240VAC)
S
PECIFICATIONS
S
PECIFICATIONS
Patton 2040 Series
V.35/X.21/RS-530-to-HSSI Converters
