Pelco Manual C527M-L (3/04) [ 35 ]
CM6800 ASCII Mode
Interface: RS-485
Protocol: Pelco ASCII
Baud: 9600
Communication
Parameters:
8 data bits, 1 stop bit, odd parity
Direct P Mode
Interface: RS-485
Protocol: Pelco P
Baud: 4800
Communication
Parameters:
8 data bits, 1 stop bit, no parity
Direct D Mode
Interface: RS-485
Protocol: Pelco D
Baud: 2400
Communication
Parameters:
8 data bits, 1 stop bit, no parity
(Design and product specifications subject to change without notice.)
This equipment contains electrical or electronic components that must be recycled properly to comply
with Directive 2002/96/EC of the European Union regarding the disposal of waste electrical and
electronic equipment (WEEE). Contact your local dealer for procedures for recycling this equipment.
