Table D. Keyboard Functions (continued)

Function

Procedure

Patterns

Programming and operation varies with the receiver type.
Spectra

domes (before version 3.0) can use one long (1 minute) or two

short (0.5 minute) patterns. Spectra domes (version 3.0), Spectra II

™

domes and Esprit

Integrated Positioning Systems can use one long

(1.5, 3 or 6 minutes) or two short (0.75, 1.5 or 3 minutes) patterns. (Select pat-
tern lengths at the positioning system’s menu.) Spectra III

™

can use four

patterns of varying length (all drawing from the same block of memory, which
is almost infinite).
To program Spectra and Esprit, select a camera (1-16)

ᕫᕹ

, select a long

pattern by holding down PATTERN

ᕫᕾ

for two seconds, or select short

pattern 1 or 2 by entering 1 or 2

ᕫᕹ

and holding down PATTERN

ᕫᕾ

for two

seconds. The monitor will indicate the programming function is active. Move
the camera position

ᕫᕵ

as desired for the pattern and press ACK

ᕫᕺ

to close

the programming function.
To run a long pattern, press PATTERN

ᕫᕾ

. To run a short pattern, enter 1 or 2

ᕫᕹ

and press PATTERN

ᕫᕾ

. Move the joystick

ᕫᕵ

or call a preset

ᕩ

to stop.

Direct Mode is the same as above, except:
Do not program a pattern with turbo pan on (switch 6).
To program Spectra III, enter 95, and then hold down PRESET

ᕩ

for about 5

seconds until the main menu appears. Use the joystick to position the cursor
beside Patterns and press IRIS OPEN

ᕫᕶ

. Position the cursor beside Pattern

Number and press IRIS OPEN

ᕫᕶ

. Position the cursor beside Program Pattern

and press IRIS OPEN

ᕫᕶ

. Follow the directions displayed on the monitor.

To run a Spectra III pattern, press the pattern number (1-4)

ᕫᕹ

and then

PATTERN

ᕫᕾ

. Move the joystick

ᕫᕵ

to stop.

Sequence*

Sequence steps through all 16 cameras. Camera number, camera title,
sequence status, and time/date are shown on the monitor.
Press PREV

to step back one camera. Hold for two seconds for a back-

ward sequence. Monitor shows B. Press during sequence to speed up. Press
during a forward sequence to reverse.
Press NEXT

to step forward one camera. Hold for two seconds for a

forward sequence. Monitor shows F. Press during sequence to speed up.
Press during a backward sequence to go forward.
Press HOLD

to hold a sequence. Monitor shows H. Press HOLD to

resume.
Manually select a camera or press CAM

ᕫᕸ

to turn off a sequence. Monitor

shows O.

Macro Sequence*

Enter 1 or 2

ᕫᕹ

and press MACRO

ᕨ

to start a group camera sequence.

Monitor

shows M. Refer to your switcher manual for macro/sequence programming.

Multiplexer Displays

Press SHIFT

ᕢ

. Shift key LED

ᕣ

lights. The function keys F1 through F3 and

the auxilary keys can now be used to display the images from multiple cam-
eras on the monitor.
F1/LATCH: Zoom
F2/OFF:

PIP display

F3/MOM: Quad display
AUX ON:

9-screen display

AUX OFF: 16-screen display
