[ 14 ]
Pelco Manual C527M-L (3/04)
Figure 4. Connecting Remote Keyboards (CM6800-48X8 Shown)
C O M 1
1
2
3
4
5
6
7
8
16
8 7
32 31
4 3
VID E O O U TP U TS
1 2 0/23 0 ~
5 0/60 H Z
2 5 WATTS
C O M
A L A R M
1 2 3 4 5 6 7 8
C O NTR O L
P TZ
O U T
A T
+
T
-
R
+
R
-
T
+
T
-
R
+
R
-
B
1 2
F
3
MAXIMUM NUMBER OF KEYBOARDS: 8 PER PORT
NOTE: THE TOTAL NUMBER OF KBD300A SERIES
KEYBOARDS CONNECTED TO THE CM6800 CANNOT EXCEED 16.
KBD300A
RJ-45 PIN-OUTS
1 Tx+
2 Tx-
3 NC
4 NC
5 GROUND
6 NC
7 Rx-
8 Rx+
CM6800 COM 7 & 8
RJ-45 PIN-OUTS
1 Rx+
2 Rx-
3 12V
4 12V
5 GROUND
6 NC
7 Tx-
8 Tx+
2
3
4 5
6
7
1 8
2
3
4 5
6
7
1 8
2
3
4 5
6
7
1 8
2
3
4 5
6
7
1 8
KBDKIT(-X)
1 REQUIRED
PER KEYBOARD
WALL
BLOCK
12V
TRANSFORMER
4-CONDUCTOR, SHIELDED,
24-GAUGE, SUCH AS BELDEN
9843 (USER-SUPPLIED)
ᕧ
ᕣ
ᕤ
ᕢ
ᕡ
KBD300A
KBD300A
KBD300A
