Chapter 2: Basic Skills
- 18 -
Main Unit (End View)
Main Unit (Back View)
Power Button
The power button performs the functions described in the table below.
Power button When the power is off When the power is on
Press and hold. The power turns on. The screen light
alternately turns on/off.
Press it quickly. The power turns on. The power turns off.
Battery Switch
The battery switch connects and disconnects the battery power from the Pocket PC.
The original factory setting of the switch is set to the right position (the “stop” side).
When using your Pocket PC for the first time, you need to set the battery switch to
the left position (the “supply” side).
Mini USB Client Port
Stylus
Battery Pack
SD Card
Battery Switch
Supply Stop
