HP Pavilion m50 15 inch Multimedia Monitor - Manual (Page 47)

5 Technical Information
HP Pavilion Multimedia Displays
44
M70 Display Information
Picture tube 17 in (43.1 cm), 90°
deflection, non-
glare, light
transmission 52%
phosphor P22 medium
short, 0.28 mm dot
pitch
Maximum
viewable area 320 mm (H) x 240 mm
(V)
12.8 in (H) x 9.6 in
(V)
Line
(horizontal)
frequency 30–70 kHz
Raster
(vertical)
frequency 50–120 Hz
Power source 100–240 VAC, 50–60
Hz
Maximum power
consumption 130 W (maximum)
Dot rate 110 MHz
Pedestal Tilt: -5° forward,
17° backward
Swivel: -45° left or
right
Dimensions
(W x H x D) 408 x 416 x 450 mm
16.3 x 16.6 x 18.0
in
