Preparation
7
[Left View]
27 A/V OUT Socket (P87)
28 USB Socket (5pin) (P88)
29 Terminal Door
[Right View]
30 Strap Eyelet (P21)
31 DC IN Socket (P14)
32 DC IN Terminal Door (P14)
[Bottom View]
33 Memory Card/Battery Door
(P12, P15)
34 Memory Card/Battery Door
Open Lever (P12, P15)
35 Tripod Receptacle
[Battery Charger/AC Adaptor]
1 AC Input Terminal
2 [POWER] Indicator
3 [CHARGE] Indicator
4 Battery Attachment Part
5 DC Output Terminal
27
28
29
31
30
32
34 33 35
2
3
5
4
1
