Switch Selectable Settings for the Model 2168:
Optional parts for the Model 2168
•
DC Power Supplies
•
Rack cards are compatible with Patton’s Model 1001R High-Density Telco Rack Chassis and Cluster
Boxes.
Optional DC Power Supplies for Standalone Units
Part Number Description
48V-PSM -48 VDC power supply, 5VDC, 1A (optional)
24V-PSM -24 VDC power supply, 5VDC, 1A (optional)
12V-PSM -12 VDC power supply, 5VDC, 1A (optional)
If you require a DC power supply with the Model 2168, you must order the 2168 without power supplies and add
the DC power supply as a separate line item.
EXAMPLE ORDER:
1 X 2168/E-2PK
Multi-Rate CopperLik Ethernet Extender Set (Local and Remote); No Power Supply
2 x 48V-PSM -48 VDC power supply, 5VDC, 1A
Shipping/Export Information
ECCN export number: 8517.50.1000
Country of origin: United States of America, NAFTA
Total weight boxed: .96lbs (.44kg) without power supply
Individual unit: .4lbs (.18kg); without power supply
G G G G o o o o C C C C ard ard ard ard
Asymmetrical
Line Rates Distance (24 AWG)
Upstream
(Mbps)
Downstream
(Mbps)
1.56 4.17 6,656’ (2.03km)
1.56 9.38 5,756’ (1.75km)
2.34 16.67 5,556’ (1.69km)
Symmetrical
Line Rates Distance (24 AWG)
Upstream
(Mbps)
Downstrea
m
(Mbps)
6.25 6.25 4,956’ (1.51km)
2 9.38 9.38 4,806’ (1.46km)
3 12.50 † 12.50 4,656’ (1.42km)
4 16.67 16.67 3,956’ (1.21km)
