PERFORM UTILITY SETUP
38
En
* The MIDI SNAP SHOT outputs all MIDI commands except MIDI START/STOP.
CENTER PANEL AREA
BOOTH MONITOR VR Bn 19 dd 0 to 127
EFFECT
AUTO/TAP BTN Bn 45 dd OFF=0, ON=127
TAP BTN Bn 4E dd OFF=0, ON=127
EFFECT CUE BTN Bn 4B dd OFF=0, ON=127
CH SELECT SW For CHANNEL SELECT and
VIDEO FX PATTERN, the
logical sum of both values
is sent.
VIDEO FX PATTERN SW Cn pc
TIME/PARAMETER SW Bn 0D MSB Bn 2D LSB
PARAMETER 1 value;
FLANGER, PHASER, FILTER,
CHORUS changed to 1/2
value; minus values of
ROBOT are converted to
positive.
LEVEL/DEPTH VR Bn 5B dd 0 to 127
EFFECT ON/OFF BTN Bn 40 dd OFF=0, ON=127
MIC HI VR Bn 1E dd 0 to 127
LOW VR Bn 1F dd 0 to 127
(FADER START)
FADER START CH1 BTN Bn 58 dd OFF=0, ON=127
FADER START CH2 BTN Bn 59 dd OFF=0, ON=127
FADER START CH3 BTN Bn 5A dd OFF=0, ON=127
FADER START CH4 BTN Bn 5D dd OFF=0, ON=127
(HEAD PHONES)
MIXING VR Bn 1B dd 0 to 127
LEVEL VR Bn 1A dd 0 to 127
TIMING CLOCK Timing Clock FB
MIDI
START BTN FA
STOP BTN FC
Category Switch Name Switch Type
MIDI Message
Commnets
MSB LSB
Category Switch Name Switch Type
MIDI Message
Commnets
MSB LSB
UTILITY BTN — — — — — —
VIDEO EQ BTN — — — — — —
JPEG VIEWER BTN — — — — — —
VIDEO SOLO
MODE BTN — — — — — —
FADER AV SYNC BTN — — — — — —
