USING THE EFFECT FUNCTION

Touch the [BPM AUTO/TAP] button to select the BPM (=Beat
Per Minute) measurement mode.
AUTO: The BPM is automatically measured from the input
music signal.
TAP: Tap the TAP button with your finger to manually input the
BPM.
• Whenever power is first turned ON, [AUTO] is selected by

default.

• The selected mode ([AUTO]/[TAP]) will appear in the

display.

• When a BPM cannot be measured automatically, the BPM

display in the display will flash.

• The measurement range of AUTO mode is BPM=70 to 180.

Depending on the track, the BPM may not be accurately
measured. In these cases, use TAP mode to manually enter
the BPM.

[Manually entering the BPM using the TAP button]

When the TAP button is tapped to the beat (a quarter note) more
than twice, the average length will be set as the BPM.
• Pressing the TAP button during [AUTO] mode will switch the

BPM measurement mode to [TAP], and the length between the
taps will be measured.

• When a BPM is set using the TAP button, the multiplication

factor will become [1/1] or [4/1] (depending on the effect), and
the effect time will be set to either the length of 1 beat (a quarter
note) or 4 beats.

• Rotate the TIME/PARAMETER dial while pressing the TAP

button to set the BPM directly.

• Touch the [BPM AUTO/TAP] button to return to [AUTO] mode.
2

Touch the effect category button [BEAT].
• The [BEAT] button will light brightly, and the icon will move

as an animation.

• The BEAT effect screen will be displayed.
• Whenever power is first turned ON, the [BEAT] effect is

selected by default.

Use the effect select buttons to select an effect type.
• The selected button will appear white, and the icon will move

as an animation.

• For a description of each effect, refer to P. 23.

Use the CH SELECT dial to select the channel to which you
wish to apply the effect.
• The selected effect channel display will appear white.
• If [MIC] is selected, the audio effect will be applied to both

MIC 1 and MIC 2. There will be no effect on the video.

• When turning the power ON, [MASTER] will be selected.

Touch the effect mode select button to select the effect
mode.
• The selected button will appear white, and the icon will move

as an animation.

A: The effect will be applied to the audio only.
AV: The effect will be applied to both the audio and video.
V: The effect will be applied to the video only.
• When turning the power ON, [AV] will be selected.

Touch the beat button to choose the multiplication factor of
the beat for synchronization of the effect.
• Select the beat number calculated from the BPM.
• The selected beat button will be highlighted.
• An effect time that corresponds to the multiplication factor

of the beat will be automatically set.

[Example] When BPM=120
1/1 = 500 ms
1/2 = 250 ms
2/1 = 1000 ms

Set the EFFECT ON/OFF button to ON to apply the effect.
• Each time the button is pressed it will switch between ON

and OFF (whenever power is first turned ON, the setting
defaults to OFF).

• When effect is ON, the button flashes.

Video effect pattern
Rotate the VIDEO FX PATTERN/TEXT BANK dial to select a video
effect pattern for the selected video effect.
For descriptions on the video effect pattern change caused by
rotating the VIDEO FX PATTERN/TEXT BANK dial, refer to P. 24.

Parameter 1
Rotate the TIME/PARAMETER dial to adjust temporal parameters
of the selected effect.
For descriptions on the changes in parameter 1 caused by turning
the TIME/PARAMETER dial, refer to P. 23.

Parameter 2
Rotate the LEVEL/DEPTH dial to adjust quantitative parameters of
the selected effect.
For descriptions on the changes in parameter 2 caused by rotating
the LEVEL/DEPTH dial, refer to P. 23.

Using the visualizer

This function allows the use of images produced internally by the
unit.
1

Set [VISUALIZER] button to [ON].
The video effect monitor displays the image.

Use the effect select buttons to choose a desired image.

Use the CH SELECT dial to select the desired channel.
• The image will move automatically in rhythm to the music’s

beat.

• In the event no input image is present, the visualizer’s image

can be used.
