E-76
Specifications
Model U4-136/U4-131/U4-112/U4-111
Optical
Method of projection : DLP™ (single chip DMD)
DMD U4-136/U4-131: 0.7 inches 1024 ן768 dots
U4-112/U4-111: 0.55 inches 800 ן600 dots
Lamp 150 W high pressure mercury lamp
Projection lens : See below
Image size See below
Light Output U4-136/U4-131: 1500 ANSI lumens
U4-112/U4-111: 1300 ANSI lumens
Contrast Ratio 1500:1 (Full on/off)
Electrical
Inputs Video (NTSC3.58/NTSC4.43/PAL/PAL-N/PAL-M/PAL60/SECAM)
RGB (Horizontal :15 to 80 kHz, Vertical 50 to 85 Hz)
Output VGA (640
ן480), S-VGA (800ן600), XGA (1024ן768)
Color Reproduction Full color (16,770,000 colors)
Resolution U4-136/U4-131: VGA (640 ן480) expansion/true, S-VGA (800ן600) expansion/true
XGA (1024
ן768) true, S-XGA (1280ן1024) compression
U4-112/U4-111: VGA (640 ן480) expansion/true, S-VGA (800ן600) true
XGA (1024 ן768) compression
Input Current 2.0 A
Power Requirement 100 - 240 V AC, 50/60 Hz
Power Consumption 200 watts
Mechanical
Dimensions Excluding Stand 190 mm (W) ן53 mm (H)ן239 mm (D)
7.5 in.(W) ן2.1 in.(H)ן9.4 in.(D)
Weight Approximately 1.5 kg / 3.3 lbs
Operational Temperatures Data projector: 5° to 35°C (41° to 95°F), 30 to 85% humidity
Regulations UL Approved (UL 60950, CSA 60950)
Meets FCC Class A requirements
Applicable Projector: U4-131/U4-111
Meets FCC Class B requirements Applicable Projector: U4-136/U4-112
Meets EMC Directive (EN55022, EN55024)
Meets Low Voltage Directive (EN60950)
• Specifications and design are subject to change without notice.
Projection lens
Image size
U4-136
Manual zoom (
ן1.2)
Manual focus
F = 2.6 – 2.9, f = 27.5 – 33.0 mm
Minimum 26 inch
(at projection distance of 1.2 m tele-
photo)
Maximum 200 inch
(at projection distance of 7.86 m
wide)
U4-111
Fixed focus
Manual focus
F = 2.4, f = 23 mm
Minimum 28 inch
(projection distance 1.2 m)
Maximum 200 inch
(projection distance 8.5 m) U4-112
Manual zoom (
ן1.2)
Manual focus
F = 2.6 – 2.9, f = 27.5 – 33.0 mm
Minimum 20 inch
(at projection distance of 1.2 m tele-
photo)
Maximum 200 inch
(at projection distance of 10.16 m
wide)
U4-131
Fixed focus
Manual focus
F = 2.4, f = 23 mm
Minimum 36 inch
(projection distance 1.2 m)
Maximum 200 inch
(projection distance 6.6 m)
Projection lens
Image size
U4-136
Manual zoom (
ן1.2)
Manual focus
F = 2.6 – 2.9, f = 1.1 – 1.3 inch
Minimum 26 inch
(at projection distance of 3.9 feet
telephoto)
Maximum 200 inch
(at projection distance of 25.8 feet
wide)
U4-111
Fixed focus
Manual focus
F = 2.4, f = 0.9 inch
Minimum 28 inch
(projection distance
3.9 feet)
Maximum 200 inch
(projection distance
27.9 feet) U4-112
Manual zoom (
ן1.2)
Manual focus
F = 2.6 – 2.9, f = 1.1 – 1.3 inch
Minimum 20 inch
(at projection distance of 3.9 feet
telephoto)
Maximum 200 inch
(at projection distance of 33.3 feet
wide)
U4-131
Fixed focus
Manual focus
F = 2.4, f = 0.9 inch
Minimum 36 inch
(projection distance
3.9 feet)
Maximum 200 inch
(projection distance
21.7 feet)
