When Replacing Cartridge

1 Slide back cover off razor. Remove empty

cartridge from razor cover and pull out the
connector. Insert the connector into a new
cartridge.The connector is secured when you
hear it click into place.

2 Rinse out razor cartridge compartment with

hot water. Shake off excess water and slide new
cartridge with connector into the Razor. Close
back cover.

When Replacing Cartridge or Once Every Month

For consistently close and comfortable shaves,
razor heads should be cleaned in a degreasing
liquid or alcohol and then lubricated.

IMPORTANT: Do NOT interchange the cutters
and combs.They are a matched set and if inter-
changed may adversely affect shaving performance
until cutters reseat themselves.Therefore,
remove, clean and replace each set individually.

1 Switch Razor OFF.
2 Press the Razor Head Release Button located

under razor heads on front side of Razor.

3 Remove the Razor Head Assembly and clean the

razor heads and hair chamber by running under
hot water. Be sure water is not too hot so as to
cause burns or scalding.

4 While holding Razor Head Assembly in one

hand, press center wheel down while turning
counterclockwise to release and lift out frame.
Set frame aside (Fig. 12).

5 Remove one cutter/comb, at a time, out of frame

(Fig. 13).
