Philips 5616X User Manual
Page 10
Inserting
Lotion
Cartridge
Replacing
Used
Cartridge
3
4
5
FIRST USE
1 Take one cartridge from the box.
2 Remove the supplied connector out of the little
bag. Push it into the plastic cap of cartridge
until you hear it “click” into place (Fig. 3).
3 Slide the back cover of razor down to remove
from razor (Fig. 4).
4 Slide the cartridge, with the connector in place,
into position in razor. The connector should
slide into the recess area with hole located at
the top of razor. The white round dot on the
connector must face down towards the razor
(Fig. 5).
5 Replace back cover on razor and press it down
into position until it snaps shut.
1 Slide back cover off razor.
2 Remove the empty cartridge from the cover
and pull out the connector. DO NOT discard
the connector.
3 Rinse out the cartridge compartment with
hot water before replacing cartridge.
Air dry thoroughly.
4 Insert the connector into the new cartridge.
Push connector into the plastic cap of cartridge
until you hear it “click” into position.
5.
