3
LOCATION OF CONTROLS
DOCKING STATION:
Front View
Backside
Bottom View
4
REMOTE CONTROL
1 Volume Rotary Knob 14 Power On/Standby
2 Speaker Charging Indicator light 15 Function button
3 Speaker 16 Menu button
4 Open button (Press to detach the
Speaker from the main base) 17 Mute button
5 Skip - Button 18 Repeat button
6 Power on Indicator/Remote sensor 19 Random Button
7 Play/Pause button 20 UP button
8 Skip + Button 21 Enter button
9 iPhone/iPod Connector 22 VOL+ Button
10 DC 9V Jack 23 VOL- Button
11 RCA Video out Jack 24 Down button
12 Aux-In Jack
13 Combination dead bolt
