APPENDIX C
PATTON MODEL 305X SERIES FACTORY REPLACEMENT PARTS
Patton Part # Description
222NM-RJ45....................RS-232 (male) to RS-422 Converter
222NF-RJ45 ....................RS-232 (female) to RS-422 Converter
222N9M-RJ45..................RS-232 (DB-9 male) to RS-422 Converter
222N9F-RJ45 ...........RS-232 (DB-9 female) to RS-422 Converter
080510ACB .............. ......Power Supply, 120V, 10VAC
080512ACI................ ......Power Supply, 230V, 12VAC
APPENDIX D
PATTON MODEL 305X LOOPBACK ADAPTER PIN ASSIGNMENTS
RS-232 LOOPBACK ADAPTER PLUG
Model 305X - LB
RJ-45 Pin No.
4 (SG)
5 (XMT)
6 (RCV)
RS-422 LOOPBACK ADAPTER PLUG
Model 305X-422-LB
RJ-45 Pin No.
6 (RCV+)
2 (RCV-)
5 (XMT+)
3 (XMT-)
