Planet Technology XRT-104D - Manual (Page 10)

5
8: Reboot the PC. Your PC will now obtain an IP address automatically from your
Broadband Router
’s DHCP server.
?
Note:
Please make sure that XRT-D ’s DHCP server is the only DHCP server
available on your LAN.
Once you
’ve configured your PC to obtain an IP address automatically, please proceed to
Step 3
2b) Windows XP
1: Click the Start button and select Settings, then click Network Connections. The Network
Connections window will appear.
2: Double-click Local Area Connection icon. The Local Area Connection window will appear.
3: Check your list of Network Components. You should see Internet Protocol [TCP/IP] on
your list. Select it and click the Properties button.
4: In the Internet Protocol (TCP/IP) Properties window, select Obtain an IP address
automatically and Obtain DNS server address automatically as shown on the following
screen.
