860 MHz, 20 dB gain power doubler amplifier BGD904L
Notes
1. Tilt = 9 dB (50 to 550 MHz); tilt = 3.5 dB at
−
6 dB offset (550 to 750 MHz).
2. Tilt = 12.5 dB (50 to 860 MHz).
3. f
p
= 55.25 MHz; V
p
= 44 dBmV; f
q
= 805.25 MHz; V
q
= 44 dBmV; measured at f
p
+ f
q
= 860.5 MHz.
4. f
p
= 55.25 MHz; V
p
= 44 dBmV; f
q
= 691.25 MHz; V
q
= 44 dBmV; measured at f
p
+ f
q
= 746.5 MHz.
5. f
p
= 55.25 MHz; V
p
= 44 dBmV; f
q
= 493.25 MHz; V
q
= 44 dBmV; measured at f
p
+ f
q
= 548.5 MHz.
6. Measured according to DIN45004B:
f
p
= 851.25 MHz; V
p
= V
o
; f
q
= 858.25 MHz; V
q
= V
o
−
6 dB;
f
r
= 860.25 MHz; V
r
= V
o
−
6 dB; measured at f
p
+ f
q
−
f
r
= 849.25 MHz.
7. Measured according to DIN45004B:
f
p
= 740.25 MHz; V
p
= V
o
; f
q
= 747.25 MHz; V
q
= V
o
−
6 dB; f
r
= 749.25 MHz; V
r
= V
o
−
6 dB;
measured at f
p
+ f
q
−
f
r
= 738.25 MHz.
8. Measured according to DIN45004B:
f
p
= 540.25 MHz; V
p
= V
o
; f
q
= 547.25 MHz; V
q
= V
o
−
6 dB; f
r
= 549.25 MHz; V
r
= V
o
−
6 dB;
measured at f
p
+ f
q
−
f
r
= 538.25 MHz.
9. The module normally operates at V
B
= 24 V, but is able to withstand supply transients up to 35 V.
CSO composite second order
distortion 49 channels flat; V
o
= 47 dBmV;
f
m
= 860.5 MHz
− −
69
−
63 dB
77 channels flat; V
o
= 44 dBmV;
f
m
= 548.5 MHz
− −
73
−
68 dB
110 channels flat; V
o
= 44 dBmV;
f
m
= 746.5 MHz
− −
69
−
63 dB
129 channels flat; V
o
= 44 dBmV;
f
m
= 860.5 MHz
− −
65
−
59 dB
110 channels; f
m
= 150 MHz;
V
o
= 49 dBmV at 550 MHz; note 1
− −
68
−
63 dB
129 channels; f
m
= 150 MHz;
V
o
= 49.5 dBmV at 860 MHz; note 2
− −
63
−
58 dB
d
2
second order distortion note 3
− −
82
−
75 dB
note 4
− −
83
−
76 dB
note 5
− −
83
−
77 dB
V
o
output voltage d
im
=
−
60 dB; note 6 62.5 64
−
dBmV
d
im
=
−
60 dB; note 7 63.5 65.5
−
dBmV
d
im
=
−
60 dB; note 8 65.5 67.5
−
dBmV
CTB compression = 1 dB;
129 channels flat; f = 859.25 MHz 47.5 48.5
−
dBmV
CSO compression = 1 dB;
129 channels flat; f = 860.5 MHz 50 52
−
dBmV
NF noise figure f = 50 MHz
−
3.8 5 dB
f = 550 MHz
−
4.1 5.5 dB
f = 750 MHz
−
4.8 6.5 dB
f = 900 MHz
−
5.9 7.5 dB
I
tot
total current consumption (DC) note 9 350 365 380 mA
SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT
