Standby Circuit
1.
When the TV is connected to the AC line, the power supply outputs 5V.
2.
This voltage is applied to the D board and the A board. The 5V applied to the D board in the
Panel Drive Section is not used during standby operation.
3. On the other hand, when the A board receives the 5V from the Power supply, it outputs the
“F_STB_ON” command.
4. This command is applied to the power supply board to generate the F_STB15V. The
F_STB15V is applied to the A board to energize the Signal SW/Process Circuit.
22
