Additional information 12
82
En
Specifications
Amplifier section
Continuous Power Output (RMS):
Front, center, surround . . . . . 100 W per channel
(1 kHz, 10 % T.H.D., 6 Ω )
Subwoofer . . . . 100 W (100 Hz, 10 % T.H.D., 6 Ω )
FM tuner section
Frequency range . . . . . . . . . 87.5 MHz to 108 MHz
Antenna . . . . . . . . . . . . . . . . . . . 75
Ω , unbalanced
AM tuner section
Frequency range
With 9 kHz step . . . . . . . . . . . 531 kHz to 1602 kHz
With 10 kHz step . . . . . . . . . . 530 kHz to 1700 kHz
(Not applicable to the Saudi Arabian model)
Antenna . . . . . . . . . . . . . . . . . . . . . . Loop antenna
Miscellaneous
Power requirements
Taiwan model . . . . . . .AC 110 V to 120 V, 60 Hz
All other models
. . . . . . . . . . . . . . . . . . AC 120–127 V/220–230 V/
240 V (switchable), 50 Hz/60 Hz
Power consumption . . . . . . . . . . . . . . . . . . . 180 W
Power consumption in standby. . . . . . . . . . 0.5 W
Dimensions
. . . . . . . 420 (W) mm x 126 (H) mm x 445 (D) mm
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9.8 kg
Accessories (DVD/CD receiver)
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
AA/R6P dry cell batteries (HTD88DVD model – to
confirm system operation) . . . . . . . . . . . . . . . . . . 2
Video cable (yellow plugs) . . . . . . . . . . . . . . . . . . 1
AM loop antenna . . . . . . . . . . . . . . . . . . . . . . . . . 1
FM antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Power cord
Central and South American models . . . . . . . 2
All other models . . . . . . . . . . . . . . . . . . . . . . . . 1
Power plug adapter (Central and South American
models, PX model) . . . . . . . . . . . . . . . . . . . . . . . . 1
These operating instructions . . . . . . . . . . . . . . . . 1
Warranty Card (Australian and PX model) . . . . .1
Speaker System
(Front speakers x2, surround speakers x2, center
speaker x1, subwoofer x1)
Front speakers (S-DV8)
Enclosure . . . . . . . . . . Closed-box bookshelf type
(magnetically shielded)
System . . . . . . . . . . . . . . . . . . . . . . . 2-way system
Speakers
Woofer . . . . . . . . . . . . . . . . . . .10 cm cone type
Tweeter . . . . . . . . . . . . . . . . . 5.2 cm cone type
Nominal impedance . . . . . . . . . . . . . . . . . . . . .6 Ω
Frequency range . . . . . . . . . . . . . 50 Hz to 20 kHz
Maximum Input Power . . . . . . . . . . . . . . . . 100 W
Dimensions
. . . . . . . 155 (W) mm x 364 (H) mm x 190 (D) mm
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.6 kg
Front speakers (S-DV88)
Enclosure . . . . . . . . . . Bass-reflex bookshelf type
(magnetically shielded)
System . . . . . . . . . . . . . . . . . . . . . . . 1-way system
Speakers
Woofer . . . . . . . . . . . . . . . . . . .10 cm cone type
Nominal impedance . . . . . . . . . . . . . . . . . . . . .6 Ω
Frequency range . . . . . . . . . . . . . 50 Hz to 20 kHz
Maximum Input Power . . . . . . . . . . . . . . . . 100 W
Dimensions
. . . . . . . 155 (W) mm x 360 (H) mm x 190 (D) mm
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.3 kg
Center speaker (S-DV8)
Enclosure . . . . . . . . . . Closed-box bookshelf type
(magnetically shielded)
System . . . . . . . . . . . . . . . . . 8.7 cm 1-way system
Speakers . . . . . . . . . . . . . . . . . . . 8.7 cm cone type
Nominal impedance . . . . . . . . . . . . . . . . . . . . .6
Ω
Frequency range . . . . . . . . . . . . . 65 Hz to 20 kHz
Maximum Input Power . . . . . . . . . . . . . . . . 100 W
Dimensions
. . . . . . . . 350 (W) mm x 120 (H) mm x 75 (D) mm
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 kg
