1.3 Features
• Wireless LAN IEEE802.11b compliant
• Solid housing provides protection against rigorous weather conditions
• Strong network security with 802.1X authentication, 64/128-bit WEP encryption, user isolation,
protocol filtering, and MAC access control
• One detachable N-type female connectors can connect to external antenna for expanding
connection distance
• 5 levels of adjustable transmit power control
• High speed data transfer rate up to 11Mbps
• Auto fall-back data rate for long-distance communication and noisy environments
• Provide powerful Windows-base SNMP utility for installation and management
• Support DHCP Client
• Power over Ethernet design
1.4 Specification
Model
WAP-5000
Standard
IEEE 802.11b
Signal Type
DSSS (Direct Sequence Spread Spectrum)
Modulation
BPSK, QPSK, CCK
Port
10Base-TX (RJ-45) * 1
Antenna Connector
N-type Female * 1
Output Power
5 levels adjustable
100mW, 50mW, 30mW, 10mW, and 5mW
Sensitivity
-84dBm
Operating Mode
AP
Security
64/128-bit WEP encryption
Password protect
802.1X security
MAC filtering
SSID Broadcast Disable function
Protocol filtering
User isolation
Frequency Band
2.4
– 2.484GHz
Data Rate
Up to 11Mbps (1/2/5.5/11)
Dimensions (L x W x H)
165 x 135 x 55mm
Weight
1130g
Environmental Specification Operating temperature: -20
– 70 degree C
