Polaris 2008 - Manual (Page 43)

40
THE PERFECT FIT
Handlebar Adjustments
When making handlebar adjustments, always be sure the handlebars,
brake lever and throttle lever operate smoothly and do not contact the
fuel tank, windshield or any other part of the vehicle when the handle-
bars are turned fully to the left or right.
Handlebar Position
Follow these steps to adjust handlebar position.
1. Remove the handlebar cover.
2. Loosen the four upper and four lower adjuster block bolts.
3. Adjust the handlebar to the desired position.
4. Torque the front bolts first, then torque the rear bolts. Torque the
bolts to 15-17 ft. lbs. (20-23 Nm).
5. Reinstall the handlebar cover.
Upper
Bolts
Lower
Bolts
