LVL Series
V
ANDAL
-R
ESISTANT
W
ET
/D
AMP
L
OCATION
L
IGHTING
Page 2 of 2
Philips Lightolier
e: [email protected]
t: (508)
679-8131
w: www.lightolier.com
LVL Series September 17, 2012
Specifications are subject to change without notice.
© Koninklijke Philips Electronics N.V., 2012. All rights reserved.
Job Information Type:
Ordering Information
Series
LV = LVL Series
Damp/Wet Location
Emergency Light
Optics
* The optics layout shown is intended to be used as reference only. Standard reflectances used were 80/50/20. Lightolier is not responsible for site specific conditions that
may alter the results.
Blank = Damp Location Listed
WL = Wet Location Listed
HR = Wet Location Listed with Battery Heater
Location Listing
Accessories (order as a separate item)
T15TPTOOL = Tamperproof Screwdriver
LV
L = Lead Calcium
Battery
W = White
B = Black
BZ = Bronze
Housing Color
Chart represents (2) luminaires mounted on 18’ centers, mounting height 8’ AFF
0.28
3'
L
0.31
0.33
0.31
0.36
0.41
0.35
0.57
0.52
1.04
1.86
1.96
1.56
3.82
3.40
1.58
3.55
2.83
0.90
1.33
0.72
0.26
0.24
0.17
0.14
0.13
0.11
0.20
0.18
0.16
0.14
0.13
0.11
0.26
0.24
0.17
0.90
1.33
0.72
1.58
3.55
2.83
1.56
3.82
3.40
1.04
1.86
1.96
0.35
0.57
0.52
0.31
0.36
0.41
0.28
0.31
0.33
2'
1'
Average initial footcandles at floor = 1.03 Minimum initial footcandles at floor = 0.28
Maximum initial footcandles at floor = 3.82 Maximum to minimum ratio = 13.7:1
9' 9'
