Panasonic D-Snap SV-AS10 - Manual (Page 59)

59
_ Checking that this unit is
recognized correctly by the PC
1
Ensure that the [Removable Disk] is
included in [My Computer].
• Drive name (E: etc.) varies with the PC
being used.
• If this unit does not operate correctly,
please check the connection again.
_ Removing the USB connection
cable safely
If the USB connection cable is removed
or the power switched off while the PC is
working, an error dialog box may appear.
In such cases, click on [OK] to close the
dialog box. To remove the USB
connection cable without the error dialog
box being displayed, proceed as follows.
1
Double click icon on the task
tray.
• The Hardware removal dialog box
appears.
• Depending on OS Windows 98SE, etc.
the icon for safe removal may not be
displayed in the task tray. (There will
be no display depending on the set up
of the OS)
Make sure that the Power/Card access
lamp of this unit is off, then remove the
cable.
