Specifications
Finish: Chassis exterior–white baked polyester enamel. Cavity- white baked
polyester enamel minimum 86% reflectance. Rust preventative undercoating
Frame: Extruded aluminum with soft white polyester powder coat finish.
Lens: One-piece vacuum formed white acrylic containing 25% DR with
decorative trim.
Electrical: Thermally protected class “P” ballast C.B.M. approved, no PCB. If
KO is within 3” of ballast, use wire suitable for at least 90°.
Labels: I.B.E.W./UL and ULc Listed.
Belmont Spill Frame
BESF2X2
Page 2 of 2
Architectural Surface Fluorescent
15-1/2" Wide, 26" Length, 4 Lamp T8 or 2 Lamp TT5
Ordering Information
Length Shielding Chassis Finish Lamp Ballast 10THD
2' BESF2X2 BE2B417UNVHI Black 4-T8 2 - 2 Lamp HI
2' BESF2X2 BE2W417UNVHI White 4-T8 2 - 2 Lamp HI
2' BESF2X2 BE2B417UNVH4 Black 4-T8 1 - 4 Lamp Elec. H4
2' BESF2X2 BE2W417UNVH4 White 4-T8 1 - 4 Lamp Elec. H4
TT5
2' BESF2X2 BE2B2FTUNVIB Black 2-TT5 1 - 2 Lamp Elec. IB
2' BESF2X2 BE2W2FTUNVIB White 2-TT5 1 - 2 Lamp Elec. IB
NOTE: Chassis and shielding shown are stock items.
Chassis
Model No. BE2W417UNVH4
with shielding BESF2X2 Chassis
Model No. BE2W2FTUNVIB
with shielding BESF2X2
BE
Options:
Add appropriate suffix to catalog no.,
ie: (GLR)
Consult factory for additional options.
Belmont
Architectural
Fluorescent
2
Fixture Width:
2 = 15 1/2¨ wide
Body Finish:
W = White
B = Black
Lamp:
(By Others)
17 = T8 17W
FT = TT5 40W
(Nominal 24")
Lamp
Quantity
4 = 4 Lamp T8
2 = 2 Lamp TT5
UNV
Ballast Type:
< 10THD
2 - 2 Lamp Elec. T8 HI † †
(17 Watt)
1 - 4 Lamp Elec. T8 H4 †
(17 Watt)
2 - Lamp Elect. TT5 IB †
(40 Watt)
† †Instant Start (UNV)
Voltage:
UNV=120-277
Chassis Code:
NOTE: Chassis and shielding are packed in separate cartons. When ordering, enter as separate line items.
LER = FP - 48.0 IW - 54.3 BF - 0.88
Comparative yearly lighting energy cost per
1000 lumens = $5.00
Report Number: G2007088
Lamp: (4) F17T8
Luminaire: 2X2 Belmont Spill Frame
Ballast: ICN-4P32-SC
Report is based on 1375 Lumens per lamp.
Efficiency: 53.9%
CIE Type - Direct
Plane:
0-Deg 90-Deg
Spacing Criteria: 1.2 1.2
Shielding Angles: 90 90
Plane: 0-Deg 90-Deg
Luminous Length: 25.200 15.000
AVERAGE AVERAGE AVERAGE AVERAGE
IN DEG. 0-DEG. 45-DEG. 90-DEG.
45 3459. 3415. 3363.
55 3184. 3131. 3082.
65 2785. 2754. 2711.
75 2129. 2243. 2290.
85 1148. 1890. 1933.
LUMINANCE DATA IN CANDELA/SQ. METER
COEFFICIENTS OF UTILIZATION –
ZONAL CAVITY METHOD. EFFECTIVE
FLOOR CAVITY REFLECTANCE 0.20
0
RC 80 50 30
RW 70 50 30 50 30 10 50 30 10
0 1 58 55 53 51 49 48 49 47 46
0 2 53 48 44 45 42 39 43 40 38
0 3 48 42 38 39 36 33 38 35 32
0 4 44 37 33 35 31 28 33 30 27
0 5 40 33 28 31 27 24 30 26 24
0 6 37 30 25 28 24 21 27 24 21
0 7 35 27 22 26 22 19 25 21 18
0 8 32 25 20 23 20 17 23 19 16
0 9 30 23 18 22 18 15 21 17 15
10 28 21 17 20 16 14 19 16 13
0.0 45.0 90.0 FLUX
0 1000 1000 1000
5 993 994 994 95
15 952 955 956 270
25 877 883 886 407
35 773 779 784 488
45 645 653 659 503
55 497 506 515 452
65 337 350 361 346
75 175 199 218 210
85 47 90 105 93
90 25 55 72
CANDELA DISTRIBUTION
ZONE LUMENS % LAMP % FIXT
0 0- 0 30 771 14.0 26.9
0 0- 0 40 1258 22.9 43.9
0 0- 0 60 2214 40.3 77.3
0 0- 0 90 2863 53.9 100.0
90-180 000 0 0.0 00 0.0
0 0-180 2863 53.9 100.0
ZONAL LUMEN SUMMARY
LER = FP - 47.6 IW - 64.75 BF - 0.88
Comparative yearly lighting energy cost per
1000 lumens = $5.04
Report Number: G2008136
Lamp: (2) TT5 40W
Luminaire: 2X2 Belmont Spill Frame
Ballast: ICN-2TTP40-SC
Report is based on 3300 Lumens per lamp.
Efficiency: 53.1%
CIE Type - Direct
Plane:
0-Deg 90-Deg
Spacing Criteria: 1.3 1.3
Shielding Angles: 90 90
Plane: 0-Deg 90-Deg
Luminous Length: 25.200 15.000
AVERAGE AVERAGE AVERAGE AVERAGE
IN DEG. 0-DEG. 45-DEG. 90-DEG.
45 4996. 5053. 5098.
55 4807. 4893. 4956.
65 4477. 4636. 4753.
75 3898. 4348. 4677.
85 3292. 5813. 6687.
LUMINANCE DATA IN CANDELA/SQ. METER
0.0 45.0 90.0 FLUX
0 1188 1188 1188
5 1182 1182 1184 113
15 1137 1141 1142 322
25 1053 1059 1062 488
35 936 943 948 590
45 788 797 804 615
55 615 626 634 559
65 422 437 448 432
75 225 251 270 265
85 64 113 130 118
90 30 69 87
CANDELA DISTRIBUTION
ZONE LUMENS % LAMP % FIXT
0 0- 0 30 923 14.0 26.3
0 0- 0 40 1513 22.9 43.2
0 0- 0 60 2688 40.7 76.7
0 0- 0 90 3503 53.1 100.0
90-180 000 0 0.0 00 0.0
0 0-180 3503 53.1 100.0
ZONAL LUMEN SUMMARY
For Factory Technical Information: (978) 657-7600 • Fax (978) 658-0595
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 a Philips Group
Section 3A/Folio H10-11 Rev. A
Job Information Type:
Lightolier is a Philips group brand
COEFFICIENTS OF UTILIZATION –
ZONAL CAVITY METHOD. EFFECTIVE
FLOOR CAVITY REFLECTANCE 0.20
0
RC 80 50 30
RW 70 50 30 50 30 10 50 30 10
0 1 57 55 52 51 49 48 49 48 46
0 2 52 47 44 44 42 39 43 40 38
0 3 47 42 37 39 36 33 38 35 32
0 4 43 37 32 35 31 28 33 30 27
0 5 40 33 28 31 27 24 30 26 24
0 6 37 29 25 28 24 21 27 23 21
0 7 34 27 22 25 21 18 25 21 18
0 8 32 24 20 23 19 16 23 19 16
0 9 30 22 18 21 18 15 21 17 15
10 28 21 16 20 16 13 19 16 13
