Philips 105E - Manual (Page 5)

Product Information
Product Features • Technical Specifications • Automatic Power Saving • Physical
Specification • Pin Assignment • Product Views
Product Features
105E11
15-inch (14.0" VIS) color monitor with excellent front of screen performance for use with MACs and
PCs ●
Autoscan covers horizontal frequencies up to 54 kHz offering a maximum resolution of 1024 x 768
with flicker free display of 800 x 600 at up to 87Hz ●
Flat square CRT with high-resolution 0.28 mm dot pitch (0.24 hdp). ●
Smallest footprint in its class requires minimum desk space: maximum depth is only 379 mm/14.9" ●
FCC, CE (in selected countries only) and ISO9241, ISO14001 certified ●
105E12
15-inch (14.0" VIS) color monitor with excellent front of screen performance for use with MACs and
PCs ●
Autoscan covers horizontal frequencies up to 54 kHz offering a maximum resolution of 1024 x 768
with flicker free display of 800 x 600 at up to 87Hz ●
Flat square CRT with high-resolution 0.28 mm dot pitch (0.24 hdp). ●
Smallest footprint in its class requires minimum desk space: maximum depth is only 379 mm/14.9" ●
FCC, CE (in selected countries only) and ISO9241, ISO14001 certified ●
RETURN TO TOP OF THE PAGE
Technical Specifications*
CRT
• Size and deflection 15 inch / 38 cm ; 90° deflection angle
• Dot pitch / Grille pitch 0.28 mm
• Horizontal pitch 0.24 mm
• Tube type
Shadow mask, flat square, anti-glare, anti-static (105E11), light
transmission 57%
• Phosphor P22
