The following is a basic formula to be used as a guide to determine current
draw. A 50% amplifier efficiency rating is used as an average. Your new
POWERCLASS
™
amplifier is more efficient, other amplifiers will probably
be less. This formula is to be used as a guideline. Using wire of a larger
gauge can only improve the current transfer of your system. Do not use
smaller gauge wire.
Total RMS output x 2 = Total Input Wattage
Total Input Wattage = Current Draw (in Amps)
Supply Voltage
Example: A
POWERCLASS
™
Pro6800 amplifier has six channels at 50
watts RMS per channel into 4 Ohms (50 x 6 = 300). You would use the
formula in the following way:
300W x 2 = 600W
600W = 50A Total current draw.
12V
If the same amplifier is driven into a 2 Ohm stereo or 4 Ohm mono load,
double it's 4 Ohm RMS rating. All
POWERCLASS
™
amplifiers will effectively
double their power at this load.
300W x 2 x 2 = 1200W
1200W = 100A Total current draw.
12V
If you are using more than one amplifier, add up the total current draw
for all of them and choose the appropriate gauge based on the grand total.
P o w e r W i r e C a l c u l a t o r
Recommended MINIMUM Gauge
Total Current Draw
Length Of Wire To Be Run
( in Amps)
Up to 4ft. 4 to 7ft.
7 to 10ft. 10 to 13ft. 13 to 16ft. 16 to 19ft. 19 to 22ft. 22 to 28ft.
0-20
14
12
12
10
10
8
8
8
20-35
12
10
8
8
6
6
6
4
35-50
10
8
8
6
6
4
4
4
50-65
8
8
6
4
4
4
4
2
65-85
6
6
4
4
2
2
2
0
85-105
6
6
4
2
2
2
2
0
105-125
4
4
4
2
2
0
0
0
125-150
2
2
2
2
0
0
0 00
(
NOTE: The ground wire should be the same gauge as the power wire.
