34
Valve Timing Assembly
REF. NO. DESCRIPTION PART NO. QTY
1 Nut, Valve Clearance Adjustment A101250 2
2 Spacer, Arm A101251 2
3 Arm A101252 2
4 Cap, Exhaust Rod A101253 1
5
Upper Retainer, Exhaust Valve
Spring
A101254 1
6 Spring, Valve A101255 2
7 Valve, Exhaust A101256 1
8 Guide Plate, Connecting Stud A101257 1
9 Rod, Connecting A101142 2
10 Upper Retainer, Intake Valve Spring A101143 1
11 Adjusting Stud, Valve Clearance A101220 2
12 Valve, Intake A101221 1
13 Stud, Connecting A101222 2
14 Camshaft A101223 1
15 Oil Seal, Valve A101224 1
MAT Engine Technologies, LLC
Lincolnshire, IL 60069
Rev. 20090217
