12

Blade Arm Assembly

REF. NO.

DESCRIPTION

PART NO.

QTY

1

Index Lever

A101121

1

2

Flatwasher

A100477

1

3

Spring, Torsion

A100510

1

4

Drive Shaft Assembly

A100987

1

4.1

Blade Arm

A100988

1

4.2

Bearing, 6203-2RS

A100498

2

4.3

Nut, M12X1.25

A100496

1

4.4

Flatwasher

A100502

1

4.5

Flatwasher

A100497

3

4.6

Key

A100499

1

4.7

Drive Shaft

A100500

1

4.8

Pulley, Half "V"

A100601

2

4.9

Nut, M12X1.25

A100492

1

4.10

Washer

A101151

1

5

Nut, M8

A100710

1

6

Spring

A100507

1

7

Nut, M8

A100450

3

8

Nut, M6

A100791

1

9

Guide, Belt

A101122

1

10

Bolt, M6X25

A100495

1

11

Bolt, M5X12

A100472

2

12

Cover, Quill Pulley

A100491

1

13

Flatwasher

A100502

1

14

Nut, M12X1.25

A100704

1

15

Blade, Edger

A100503

1

16

Bolt, Carriage

A100504

3

17

Blade Guard, Assembly

A101124

1

17.1

Label, Blade Danger

A100993

1

17.2

Blade Guard

For Reference Only

1

18

Belt

A101152

1
