Getting Started
13
English
•
To configure a wireless camera with a wired/wireless switch, such as the
BL-C30, set the switch to WIRED during Quick Setup.
3.
Connect the camera to the power outlet.
4.
Wait while the Quick Setup utility restarts, configures, and registers the
camera.
•
When the camera has been configured and registered, [Finished] is
displayed next to the camera name ([CAM1], for example) and the buzzer
sounds.
•
If [This camera’s firmware is out of date] is displayed, you must update the
camera’s firmware. Refer to the information on page 6. It is also
recommended that you erase the camera (see “Erasing a Camera” on
page 104 of the Operating Instructions) and then register it again.
Ethernet cable
LAN jacks
Rear panel of
BL-WV10
Router
Bottom of BL-C30
Rear panel
of camera
To
power
outlet
