5
Operations on the Amplifier and Cable Connections
To display reverberation characteristics measured with the amplifier on your PC, you need to connect the
amplifier to the PC.
1
Connect the amplifier to your PC with a RS-232C cable.
Caution
Before making or changing connections, switch off the power and disconnect the power cord from
the power outlet. Plugging in components should be the last connection you make with your system.
VSA-AX10Ai
PC
RS-232C RS-232C
VIDEO VIDEO AUDIO DVR/VCR1 VCR2 VCR3 CD TUNER PHONO CD-R/ TAPE1/MD MULTI CH INPUT
LISTENING MODE SELECTOR TURN/PUSH
MASTER VOLUME
VSX-59TXi AUDIO/VIDEO MULTI-CHANNEL RECEIVER
Female-female
cross cable
Note
• The type of cable to use is a female-female cross cable. Different manufacturers use different names
to refer to this type of cable. Sometimes it is called an “interlink” cable, and sometimes it is called a
“reverse” cable.
Pin-out diagram of RS-232C cable to connect amplifier and PC
2
3
4
5
6
7
8
2
3
4
5
6
7
8
2
3
4
5
6
7
8
3
2
6
5
4
8
7
Dsub 9-pin female Dsub 9-pin female Dsub 9-pin female Dsub 9-pin female
Continue Continue
