l The Power LED should be ON.
l Status LED should flash, and then turn off. If it stays on, there is a hardware
error.
l For each LAN connection, one of the LAN LEDs (10, 100, or 1000) should be
ON (provided the PC is also ON.)
l One of the WAN LEDs (10, 100, or 1000) should be ON, provided the Broad-
band modem is powered up.
2.2 Configuration
Then, you need to setup your LAN PC clients, so that it can obtain an IP address
automatically. By default the XRT-501’s DHCP server is enabled, so you can obtain
an IP address automatically.
Note
Please make sure that the XRT-501’s DHCP server is the only DHCP
server available on your LAN. If there is another DHCP on your
network, then you’ll need to switch one of the DHCP servers off.
Once your PC has obtained an IP address from your router, please start your Web
Browser. In the Address box, enter http://192.168.0.1, and then press
The login screen below will appear. Enter the “User Name” and “Password” and
then click to login.
Note
By default, the user name and password both are “admin”. For
security reasons it is recommended to change the password at the
first login and memorize it.
