16 www.pridemobility.com Jazzy 1170 XL Plus
I I I . Y O U R P O W E R C H A I R
AMMETER
CONTROLLER CONNECTOR
(VSI SHOWN) CHARGER INHIBIT CONNECTOR
(VSI ONLY)
CHARGER POWER CORD
Figure 6. Jazzy 1170XL Plus Power Base (Shroud Removed)
Figure 7. Jazzy 1170XL Plus Electronics Tray
MAIN CIRCUIT
BREAKER
BATTERY
ELECTRONICS TRAY
FREEWHEEL LEVER
FREEWHEEL LEVER
BATTERY
MOTOR/BRAKE ASSEMBLY
ONBOARD BATTERY CHARGER
(LOCATED UNDER ELECTRONICS TRAY)
