14 www.pridemobility.com Jazzy 1170 XL Plus
SEATBACK
ARMRESTS
ANTI-TIP WHEELS
DRIVE WHEEL
CASTER WHEEL
Figure 5. The Jazzy 1170 XL Plus
POWER BASE
ASSEMBLY
SEAT ASSEMBLY
FOOT RIGGING
(FOOT
PLATFORM
SHOWN)
THE JAZZY 1170 XL PLUS
The Jazzy 1170 XL Plus has two main assemblies: the seat and the power base. See figures 5 and 6. Typically, the
seat assembly includes the armrests, seatback, and seat base. The power base assembly includes two motor/brake
assemblies, two drive wheels, two anti-tip wheels, two caster wheels, two batteries, and wiring harnesses.
HEADREST
SEAT BASE
I I I . Y O U R P O W E R C H A I R
CONTROLLER
(VSI SHOWN)
