APPENDIX B
MODEL 1075 FACTORY REPLACEMENT
PARTS AND ACCESSORIES
Patton Model #
Description
1075 ................................KiloModem II X.21 Short Range Modem
0805B ..............................120V Wall Mount AC Adapter
08059DCI ........................230V AC Adapter (No Power Cord)
0805US ...........................American Power Cord
0805EUR.........................European Power Cord CEE 7
0805UK ...........................United Kingdom Power Cord
0805AUS .........................Australia/New Zealand Power Cord
0805DEN.........................Denmark Power Cord
0805FR............................France/Belgium Power Cord
0805IN.............................India Power Cord
0805IS .............................Israel Power Cord
0805JAP..........................Japan Power Cord
0805SW...........................Switzerland Power Cord
APPENDIX C
MODEL 1075 X.21 Interface
DB15 Female
Pin
Signal
Source
1
Shield
-
2
Transmit (a)
DTE
3
Control (a)
DTE
4
Receive (a)
DCE
5
Indication (a)
DCE
6
System Clock (a)
DCE
7
-
-
8
Signal Ground
-
9
Transmit (b)
DTE
10
Control (b)
DTE
11
Receive (b)
DCE
12
Indication (b)
DCE
13
System Clock (b)
DCE
14
-
-
15
-
-
17
18
