UNASSEMBLED PARTS

Steering Wheel

Seat

(2) Keys

Slope Sheet

Keys

Steering

Wheel Insert

Gauge Wheel

Steering

Wheel Adapter

Steering Sleeve

Steering Sleeve

Extension

(1) Oil Drain Tube
For Future Use

(2) Washers

3/8 x 3/4 x 14 Ga.

(2) Wheels

(2) Adjusting Bar

(4) Retainer Springs
(double loop)

(2) Clevis Pins

(2) Locknut

3/8-16

(2) Shoulder Bolt

(1)Front Plate
Assembly

(2) Retainer Springs

(single loop)

(2)Flanged
Pins

Mower

(2) Retainer Springs
(double loop)

(1) Knob

(1) Washer
17/32 x 1-3/16 x 12 Gauge
