Electrical and Technical Data
RMS Lamp Operating Current (Amps) Nominal ——————————— 1.5 (175W)
—————————————————————————————— 2.1 (250W)
—————————————————————————————— 3.0 (360W)
————————————————————————————— 3.25 (400W)
————————————————————————————— 4.1 (1000W)
Lamp Current Crest Factor (Maximum)——————————————————1.8
Warm-up to 80% Full Brightness ———————————————— 3–5 minutes
Re-start Time for Hot Lamps —————————————————10–20 minutes
Physical Characteristics
Bulb Temperature (Maximum) ————————————————— 400°C (752°F)
Base Temperature (Maximum)————————————————— 210°C (410°F)
Base —————————————————————————— EX39 Excl. Mog.
Operating Position ————————————————————— Base-up ± 15°
Luminaire ——————————————————————— Open or Enclosed
Standard Package Quantity —————————————————12 (175W, 250W)
———————————————————————— 6 (360W, 400W, 1000W)
