APPENDIX A

PATTON MODEL 111OARC SPECIFICATIONS

Transmission Line:

Dual optical cable

Transmission Mode:

Asynchronous, half or full duplex, point-to-
point

Interfaces:

EIA RS-232, CCITT V.24

Data Rates:

0 - 19.2 Kbps

Distance:

4 miles over continuous fiber

RTS/CTS Delay:

Switch-selectable: No delay, 9.0 mS, 79.5
mS

Receiver Sensitivity:

-45 dBm

Coupled Power Output: -20 to -25 dBm

Optic Wavelength:

850 nm

LED Indicators:

Power, TD, RD, RTS, CD

Connectors:

HD-26 female on RS-232 side; ST or SMA
connectors on fiber side

Temperature Range:

0-60°C (32-140°F)

Altitude:

0-15,000 feet

Humidity:

Up to 95% non-condensing

Weight:

2 oz.

Dimensions:

0.95”W x 3.1”H x 5.4”L

APPENDIX B

PATTON MODEL 1110ARC FACTORY REPLACEMENT PARTS

The Patton Model 1110ARC rack system features interchangeable

rear half cards, power cords/fuses for international various operating
environments and other user-replaceable parts. Model numbers and
descriptions for these parts are listed below:

Patton Model #

Description

1000RPEM..........................120/240V Rear Power Entry Module
1000RPSM-2.......................120/240V Front Power Supply Module
1000RPEM-DC ...................DC Rear Power Entry Module
1000RPSM-48A ..................48V Front Power Supply Module
1000RPEM-V ......................120/240V CE Compliant Rear Power

Entry Module

1000RPSM-V ......................120/240V CE Compliant Front Power

Supply Module

0805US ...............................American Power Cord
0805EUR.............................European Power Cord CEE 7
0805UK ...............................United Kingdom Power Cord
0805AUS.............................Australia/New Zealand Power Cord
0805DEN.............................Denmark Power Cord
0805FR ...............................France/Belgium Power Cord
0805IN.................................India Power Cord
0805IS.................................Israel Power Cord
0805JAP..............................Japan Power Cord
0805SW ..............................Switzerland Power Cord

05R16FPB1.........................Single Width Blank Front Panel
05R16FPB4.........................4-Wide Blank Front Panel
05R16RPB1 ........................Single Width Blank Rear Panel
05R16RPB4 ........................4-Wide Blank Rear Panel

0821R4................................400 mA Fuse (5x20mm)

Littlefuse 239.400 or equivalent

0821R2................................200 mA Fuse (5x20mm)

Littlefuse 239.200 or equivalent

056S1..................................Set of 16 #4 pan head screws/washers
