To reinstall the battery system
1 Install new batteries into the tray. Replace both batteries at the same time.
Do not mix old and new batteries
2 Reconnect the battery cables to the controller board and to the four battery
terminals. Be sure that cable and terminal connections match RED-to-RED and
BLACK-to-BLACK. Push in each connector until you feel the connection click.
3 Reattach the retaining bracket with the two Phillips screws.
4 Push the battery tray all the way into the enclosure.
5 Reinsert the fuses. Use the flathead screwdriver to make a quarter turn
clockwise to secure each connection. Do not overtighten.
6 Plug in the power cord, USB cable, and power output cable.
7 Reinsert the Phillips screws on the back and front of the enclosure.
