26
Attaching the lens
1
Raise the lever for securing the lens, and detach
the mount cap.
2
Align the center mark of the lens with the groove in
the top center of the lens mount, and attach the
lens.
3
Push down the lever for securing the lens to
secure the lens.
4
Push the cable into the cable clamp, and connect it
to the LENS socket.
O
For details on handling the lens, refer to the
operating instructions which accompany the lens.
O The following lens adjustments and camera
adjustments may be necessary depending on the
lens mounted.
1. Lens flange back adjustment
2. Lens auto iris operating speed adjustment
3. Lens white shading adjustment (performed on
the unit)
Lever for securing
the lens
Mark
LENS socket Mount cap
