Philips Pacific II TCW097 - Manual

127 110
A
C
B
D D
Note I = electromagnetic ballast I C = electromagnetic ballast + capacitor HFE = electronic ballast (EB -S) for TL’D lamps HFA = electronic ballast for TL’5 lamps
Standard products with electromagnetic ballast are for 220V 50Hz system (Specification subject to change without prior notice)
Measurements in mm
Product dimensions
Ordering data
1xTL’D 18W
1xTL’5 14W TCW097
660
100
676
417
1xTL’D 36W
1xTL’5 28W
1270
100
1276
880
1xTL’D 58W
1xTL’5 35W
1570
100
1586
590
A
B
C
D
lighting solutions that really last
Excellent water and dust protection
Impact-resistant
Optimum light distribution and performance
Easy installation and maintenance
TCW097 Pacific II
waterproof luminaires
w w w. l i g h t i n g . p h i l i p s . c o m / ap r
© Koninklijke Philips Electronics N.V. 2003
All rights reserved, reproduction in whole or in part without permission is prohibited.
Lamp
1 x TL’D 18W
1 x TL’D 18W
1 x TL’D 18W
1 x TL’D 36W
1 x TL’D 36W
1 x TL’D 36W
1 x TL’D 58W
1 x TL’D 58W
1 x TL’D 58W
2 x TL’D 18W
2 x TL’D 18W
2 x TL’D 18W
2 x TL’D 36W
2 x TL’D 36W
2 x TL’D 36W
2 x TL’D 58W
2 x TL’D 58W
2 x TL’D 58W
1 x TL’5 14W
1 x TL’5 28W
1 x TL’5 35W
2 x TL’5 14W
2 x TL’5 28W
2 x TL’5 35W
For TL’D Lamps
TCW097 1XTL-D18W HFE
TCW097 1XTL-D18W I
TCW097 1XTL-D18W IC
TCW097 1XTL-D36W HFE
TCW097 1XTL-D36W I
TCW097 1XTL-D36W IC
TCW097 1XTL-D58W HFE
TCW097 1XTL-D58W I
TCW097 1XTL-D58W IC
TCW097 2XTL-D18W HFE
TCW097 2XTL-D18W I
TCW097 2XTL-D18W IC
TCW097 2XTL-D36W HFE
TCW097 2XTL-D36W I
TCW097 2XTL-D36W IC
TCW097 2XTL-D58W HFE
TCW097 2xTL-D58W I
TCW097 2XTL-D58W IC
For TL’5 Lamps
TCW097 1XTL5-14W HFA
TCW097 1XTL5-28W HFA
TCW097 1XTL5-35W HFA
TCW097 2XTL5-14W HFA
TCW097 2XTL5-28W HFA
TCW097 2XTL5-35W HFA
Gross
weight (kg)
2
2.1
2.1
2.8
2.9
2.9
4.8
4.9
4.9
2.4
2.6
2.6
4.6
4.8
4.8
6
6.2
6.2
2
2.8
4.8
2.4
4.6
6
Ordering number
9104 019 83680
9104 019 83880
9104 019 84080
9104 019 84680
9104 019 84880
9104 033 20080
9104 033 20280
9104 033 20480
9104 033 20680
9104 033 21080
9104 033 21280
9104 033 21480
9104 033 22080
9104 033 22380
9104 033 22480
9104 033 22680
9104 033 22880
9104 033 23080
9104 019 83480
9104 019 84280
9104 019 84480
9104 033 20880
9104 033 21680
9104 033 21880
Packing
dimensions (
mm )
664 x 108 x 99
664 x 108 x 99
664 x 108 x 99
1274 x 108 x 99
1274 x 108 x 99
1274 x 108 x 99
1574 x 108 x 99
1574 x 108 x 99
1574 x 108 x 99
664 x 158 x 99
664 x 158 x 99
664 x 158 x 99
1274 x 158 x 99
1274 x 158 x 99
1274 x 158 x 99
1574 x 158 x 99
1574 x 158 x 99
1574 x 158 x 99
664 x 108 x 99
1274 x 108 x 99
1574 x 108 x 99
664 x 158 x 99
1274 x 158 x 99
1574 x 158 x 99
Quantity
per box
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
32 1-B27 3 002-01
2xTL’D 18W
2xTL’5 14W TCW097
660
150
676
417
2xTL’D 36W
2xTL’5 28W
1270
150
1276
880
2xTL’D 58W
2xTL’5 35W
1570
150
1586
590
A
B
C
D
