Pitco Frialator SG14 - Manual (Page 2)

Model SG Tube Fired, Gas Fryer - With SoloFilter
Pitco Frialator, Inc., P.O. Box 501, Concord, NH 03302-0501 • 509 Route 3A, Bow, NH 03304, USA
Phone (603) 225-6684 • FAX (603) 225-8472 L10-152 Rev 2 (02/07) Printed in USA
We reserve the right to change specifications without notice and without incurring any obligation for equipment previously or subsequently sold.
M
o
d
e
l
S
G
T
u
b
e
F
ir
e
d
,
G
a
s
F
ry
e
r
-
W
it
h
S
o
lo
F
il
te
r
INCHES [CENTIMETERS]
34 3/8 [87.3]
1 15/32 [3.7]
13 3/8 [34.0]
5/8 [1.6]
47 1/8 [119.7]
11/16 [1.8]
21 29/32 [55.6]
1 13/32 [3.6]
4 3/8 [11.1] 1 25/32 [4.5]
16 1/16 [40.8]
Dim A
NOM.
35 [88.9]
(NEMA 5-15 PLUG ON 115VAC UNITS ONLY)
6 FOOT (183 CM) POWER CORD SUPPLIED
INTEGRAL
FLUE DEFLECTOR
FULL PORT DRAIN VALVE
1-1/4 INCH (3.2 CM) NPT
GAS
CONNECTION
¾ INCH NPT.
11
[27.9] NOM.
31 1/8 (79) minimum
aisle space required
to remove filter pan.
55 7/16 [140.8]
OPTIONAL
BASKET LIFT
52 5/16 [132.9] 3 27/32 [9.8]
OPTIONAL
BACK-UP
THERMOSTAT
See Cook Area Below
Gas Type Store Manifold Pressure* Burner Manifold *Recommended Minimum
Natural Gas 7” W.C. / 17.4 mbars / 1.75 kPa 4” W.C. / 10 mbars / 1 kPa
L.P. Gas 13” W.C. / 32.4 mbars / 3.25 kPa 10” W.C. / 25 mbars / 2.5 kPa
Check plumbing/gas codes for proper gas supply line sizing.
Clearance Information Fryer Front
Fryer Sides, Rear, Bottom
to any combustible material
Fryer Flue Area
All Models 30” (76.2 cm) minimum
6” (15.2 cm)
Do not Curb Mount
Do not block or restrict flue gasses from flowing into
ventilation system.
ELECTRICAL REQUIREMENTS
Options Voltage / Phase / Frequency Amps
Additional Amps
for Filter Heater
Number
of Power cords
Power
Cord Locations
1 Back Left
GAS REQUIREMENTS
Models “A” Dim Cook Area
Oil
Capacity
Gas
Input / Hour
Shipping
Weight / Unit
Shipping
Cube
Shipping Dimensions
H x W x L
SG14
15-5/8 in
39.7 cm
14 x 14 x 4 in
35.6 x 35.6 x 10.2 cm
40-50 lbs
18-23 kg
110,000 BTU
33 kW (CE) / 119 mJ (AuGA)
200 lbs
91kg .93 m
3
3
58 x 22½ x 43½ in
147.3 x 57.2 x 110.5 cm
SG14R
15-5/8 in
39.7 cm
14 x 14 x 4 in
35.6 x 35.6 x 10.2 cm
40-50 lbs
18-23 kg
122,000 BTU
36 kW (CE) / 129 mJ (AuGA) 94kg
58 x 22½ x 43½ in
147.3 x 57.2 x 110.5 cm .93 m
3
3
SG18
19-5/8 in
49.8 cm
18 x 18 x 4 ~ 4 ¾ in
45.7 x 45.7 x 10.2 ~12.1 cm
70-90 lbs
32-41 kg
140,000 BTU
40 kW (CE) / 145 mJ (AuGA)
226 lbs
103 kg
58 x 22½ x 43½ in
147.3 x 57.2 x 110.5 cm
SoloFilter N/A N/A N/A 100 lbs / 46 kg
N/A
Ships with
fryer
N/A
SHORT FORM SPECIFICATION
Provide Pitco FD (Filter Drawer) Solstice filter system. Drain line shall be 3” (7.6 cm) diameter with a swivel drain spout for oil disposal. Filter pickup assembly shall have
handles and
assembly. Filter lid shall be attached to the cabinet for ease
of use. Filter pan shall have front stabilizer legs and rear rigid casters for portability. Provide accessories as follows.
utilize envelope type filter paper with 475 sq in (3,065 sq. cm.) of filter area for model SG18 and 310 sq in (2,000 sq cm) of filter area for model SG14, SG14R
and SG14T. Filter pump shall pump 8 GPM, 60 Hz (25.4 LPM, 50 Hz). Filter piping to be self-aligning for easy
TYPICAL APPLICATIONS
Space saving filter capable of filtering heavy to light breaded products fast and conveniently.
.93 m
3
3
8.0 GPM (30.3 LPM) 1/3 HP 115 / 1 / 60 7 3
Filter
6.7 GPM (25.4LPM) 1/3 HP 220-230-240 / 1 / 50 3.6 1.5
Millivolt controls Not Required 0 N/A
115 / 1 / 60 1.7 N/A Fryer Upgrade Controls: Solid state,
Digital, Computer, Basket Lift 220-230-240 / 1 / 50 0.9 N/A
