I
Installation Guide
1
This unit should be installed by a qualified service Technician.
2
This product is designed to operate with a 12V DC, negative ground
battery system.
3
Don t connect the ground wire from the battery terminal prior to
connecting the unit to the electrical system.
4
Please use accessories that come with this unit in order to avoid fire or
electrical damage to it.
'
6
6
Menu
Power ON/OFF button
Channel increase
Analog decrease
Analog increase
Channel decrease
7
7
11
11
8
8
10
10
12
12
1
1
Open button
2
2
Left light control button
3
3
Right light control button
4
4
Left light
5
5
Right light
9
9
Remote window
II
Performance Parameter
Panel size: 7"
Display mode: 16:9
System: NTSC/PAL
Power supply: DC 12V
Power consumption: 12W
Resolution: 480
RGB
234
Operation temperature: +5
+40
Storage temperature: -5
+75
2
Brightness: 300cd/m
Contrast: 300:1
Built-in TV Tuner
IR Transmitter
III
Remote Control
IV
Connection
Red to battery +12V
Black to grounding
Yellow to Video
Inset to LCD S terminal
Inset to LCD S terminal
4
4
5
5
7
7
6
6
8
8
10
10 11
11 12
12
9
9
1
1
1
1
3
3
2
2
Audio Left
Audio Right
Red to battery +12V
Black to grounding
Yellow to door control
Mute
Channel increase+
Volume -
TV/AV
Number key
Channel decrease -
Mirror
Picture System
Return key
Sleep time
Volume +
View mode
Menu
Power on /off
0
90
0
18
0
0
0
TV ANT
