Pride Mobility JET2 - Manual (Page 17)

Jet 2/Rev F/Feb03 www.pridemobility.com 17
I V . Y O U R J E T 2
SPECIFICATIONS
Suspension: Limited
Drive Wheels: 14 in. solid, center-mounted (pneumatic tires are optional)
Caster Wheels: 8 in. solid, rear articulating
Anti-tip Wheels: 6 in. solid, front mounted
Maximum Speed: Up to 4.5 mph
Brakes: “Intelligent Braking,” electronic regenerative, disc park brake
Ground Clearance: 3 in.
Turning Radius: 19.5 in.
Overall Size: Length: 38 in.
Width: 23.5 in.
Seating Options: Medium Back (standard)
High Back with headrest
Drivetrain: Two motor, mid-wheel
Batteries: NF-22 batteries
Range: Up to 25 miles
Battery Charger: 4-amp Onboard (standard)
4-amp Off-board
Electronics: 50-amp Dynamic DL controller
Weight Capacity: 300 lbs.
Jet 2 Weights: Base: 96 lbs.
Seat: 36.5 lbs.
Batteries: 38 lbs.
Warranty: Five-year limited warranty on frame
One-year warranty on electronics
One-year warranty on drive motors
