UNIVERSAL DOCKING STATION USER’S GUIDE
8
Do NOT connect a
standard telephone
line on the same
line and pair as
Dock-N-Talk™ Plug telephone line cord into
one or both of Dock-N-Talk’s
modular telephone jacks
Warning: Do not attempt to connect the Dock-N-Talk™ telephone service to
an active land line telephone service.
If you have local wireline telephone service, use a different pair of wires to connect
the Dock-N-Talk™ to the extension telephones. Use the supplied long line cord to
connect to a RJ-11 modular wall jack for local extension telephones by plugging
one end of the line cord into the wall modular connector and connect the other
end into the back of the Dock-N-Talk™. The Dock-N-Talk™ RJ-11 modular jacks
are in parallel and it does not matter which one is used for a local telephone or
for the modular wall jack. Press the ringing “ ” button to verify the telephone sets
connected ring properly.
