UNIVERSAL DOCKING STATION USER’S GUIDE
12
The following describes the two different test modes:
(1) Short Ring: Pressing down the key for less than one second will cause a short
ring burst to extension sets.
(2) Long Ring: Pressing and holding down the key for at least one second then
releasing it will provide two long rings to the extensions sets. The long ring is
useful to confirm which telephones are connected to the Dock-N-Talk™. The
software version information is sent via Caller ID to extension telephones
between rings.
%OXHWRRWK3DLULQJ.H\
Bluetooth operation requires the connection of the Phone Labs Bluetooth Module
into the connector slot on the top right side of the Dock-N-Talk™. Bluetooth devices
must be paired before they can communicate. Normally, pairing needs to only be
performed once. The Bluetooth Module is capable of pairing with up to 8 cell phones
but only one can be connected at a time. Press and hold the Bluetooth Pairing Key
for at least three seconds until both the green LED on the Dock-N-Talk and the blue
LED on the Bluetooth Module start to flash rapidly. The Dock-N-Talk™ will enter into
discoverable mode where it is expecting to discovered by a bluetooth enabled cellular
handset. You must then initiate bluetooth pairing from the cell phone by having the
cell phone locate the Phone Labs device. Once you select it, the cell phone will
prompt you to enter a password or pass key.
7KHGHIDXOWSDVVZRUGLVOnce
the Dock-N-Talk™ and cell phone are paired, the LEDs will turn solid green and blue
confirming the Bluetooth connection has been established.
