ProForm PFES80040 - Manual (Page 6)

6
3. Attach the Upright Stabilizer (10) to the Upright
Base (1) with two M10 x 78mm Button Screws
(101) and two M10 Split Washers (114).
4. Identify the Right Rail (6). Carefully tip the Upright
Base (1) and the Seat Base (2) onto the left side.
Attach the Right Rail to the Upright Base with four
M10 x 25mm Screws (86) and four M10 Large
Zinc Washers (82).
Turn the Base Knob (44 [not shown]) out and
attach the Left Rail (5 [not shown]) in the
same manner.
1
10
114
114
101
3
4
6
86
82
82
82
82
86
1
2
86
86
2. Attach the Seat Stabilizer (9) to the Seat Base (2)
with two M10 x 78mm Carriage Bolts (149) and
two M10 Nylon Locknuts (81).
2
9
2
81
81
149
