Pride Mobility SC155 - Manual (Page 31)

31 Rally/RevF/September 03 www.pridemobility.com
V I I I . C O M F O R T A D J U S T M E N T S
Figure 12. Front-To-Back Seat Adjustment
Figure 13. Armrest Width Adjustment
ADJUSTMENT
KNOBS
ARMRESTS
SEAT
FRAME
Figure 14. Seat Lock Lever
FRONT-TO-BACK SEAT ADJUSTMENT
You can reposition the scooter’s seat forward or back-
ward to one of three settings to adjust the distance
between the seat and the tiller. See figure 12.
1. Remove the seat from your scooter.
2. Remove the four bolts that fasten the seat to the
seat platform. See figure 12.
3. Align the seat platform with the desired set of holes
on the seat.
4. Install the four bolts securely.
ARMREST WIDTH ADJUSTMENT
The armrest width of your scooter can be adjusted
inward or outward. See figure 13.
1. Loosen the adjustment knobs at the back of the
seat frame.
2. Slide the armrests in or out to the desired width.
3. Tighten the adjustment knobs.
NOTE: The armrests also raise up, making get-
ting onto and off of your scooter easier.
SEAT ROTATION
The seat lock lever locks the seat in one of eight posi-
tions. See figure 14.
1. Push forward on the seat lock lever to unlock the
seat.
2. Rotate the seat to the desired position.
3. Release the seat lock lever to lock the seat securely
in place.
SEAT LOCK
LEVER
SEAT
PLATFORM
SEAT
BOLTS
PUSH
FORWARD
TO ROTATE
SEAT
